Grundfos Pump Seal

ISP GLF-2 IS SINGLE SRING ,O-RING MOUNTED SEMI-CARTRIDGE SEALS WITH PUSH-FIT HEAD. SUIT FOR GRUNDFOS CR,CRN,CRI SERIES PUMPS.

1,OPERATIONAL CONDITIONS:
   TEMPERATURE:  -30 ℃to +200 ℃
       PRESSURE: ≦ 2.5MPa
              SPEED: ≦25M/S

2,MATERIAL:
       STATIONARY RING: CAR/ SIC/ TC
           ROTARY RING: CAR/ SIC/ TC
        SECONDARY SEAL: VITON/ EPDM/ AFLAS/ KALREZ
SPRING AND METAL PARTS: SS/ H-C

3,APPLICATIONS:
     CLEAN WATER, WEWAGE WATER, OIL AND OTHER MODERATELY CORROSIVE FLUID.

4,SIZE: 12MM, 16MM

5,PACKING: IN CARTON

6,DELIVERY TIME: ABOUT 20DAYS OR DEPENDS ON THE QUANTITY

7,PAYMENT: T/T OR WESTERN UNION

8,MOQ:10 SET PER ITEM

WELCOME TO INQUIRE US FOR THE DETAILED INOFRMATION OF THE TYPE SEAL
