multi-spring mechanical seal

multi-spring mechanical seal
Product name : multi-spring mechanical seal
Item : ISP C9B
Details :

Multi Spring Mechanical Seals

They are commonly used Mechanical Seals for clear liquids in most of equipments. Multi-Spring design has many springs put uniform force over the faces hence increase its life. Multi-Spring Seals are unitised, compact, simple & easy to install.These are Bi-directional Pusher type Mechanical Seals suitable to all type of elastomers. Such Mechanical Seals are available in Un-balance design for low pressure and Balance design for high pressure applications.These Seals can be designed in Double configuration for toxic, hazardous, costly & volatile liquids. We can offer Double Seals in Back to Back as well as Tandem arrange-ment as per application. Most of components are interchangeable, hence it proves economical and easy to maintain.We have variety of shapes & designs in this category.

1,OPERATIONAL CONDITIONS:
   TEMPERATURE:  -50 ℃to +200 ℃
       PRESSURE: ≦ 1MPa
              SPEED: ≦20M/S

2,MATERIAL:
       STATIONARY RING: CAR/ SIC/ TC
           ROTARY RING: CAR/ SIC/ TC
        SECONDARY SEAL: VITON/ EPDM/ AFLAS/ KALREZ
SPRING AND METAL PARTS: SS/ H-C

3,APPLICATIONS:
     CLEAN WATER, WEWAGE WATER, OIL AND OTHER MODERATELY CORROSIVE FLUID.

4,SIZE: THE SAME AS AES ORIGINAL ITEM. FROM 1 INCH TO 4 INCH.

5,PACKING: IN CARTON

6,DELIVERY TIME: ABOUT 20DAYS OR DEPENDS ON THE QUANTITY

7,PAYMENT: T/T OR WESTERN UNION

8,MOQ:10 SET PER ITEM


WELCOME TO CONTACT US TO GET THE DETAILED INFORMATION OF THIS ITEE.
